    Brass, SAE J514 37° Flare 90° Male Elbow, 3/8" Male JIC x 1/8" Male NPTF 30°

    Product Image

    Product photo may not represent actual item. Please see product details for more information.

    Brass, SAE J514 37° Flare 90° Male Elbow, 3/8" Male JIC x 1/8" Male NPTF 30°

    SKU 2501-06-02-B
    $ 232.00 - $ 232.00
    $ 232.00
    $ 232.00 - $ 232.00
    $ 232.00
      Product Attributes:
    • #6 JIC Thread
    • 1/8" NPTF Thread
    • 90 Elbow
    • Brass
    • Hydraulic Adapters
    • Male Rigid

    The 2501-06-02-B from Brennan Industries is a brass 90° elbow — a 90° elbow fitting that changes hydraulic line direction at a right angle. Built for use in hydraulic, fluid power, and pneumatic systems.

    Material Brass
    Plating None
    Shape 90° Elbow
    Side 1 Connection Male JIC 37° Flare
    Side 1 Thread Size 9/16-18 UNF
    Side 1 Standard SAE J514 (Class 2A Thread)
    Side 2 Connection Male NPTF
    Side 2 Thread Size 1/8-27 NPT
    Side 2 Standard SAE J476 / ANSI B1.20.3
